HX125/25 Type Corn Mill Mazie Miller Grinder Machine for Wheat and Other Grains

Product properties
  • Summary:

    HX125/25 Type of corn mill maize miller grinder machine for corn and wheat, belongs to the HX pneumatic miller series. It is widely used in large and medium corn, coarse grains and wheat co-production complete set of equipments project.

Brief Introduction

HX125/25 Type of corn mill features:
advanced structure, complete specifications, new and beautiful appearance, reasonable design.

Function and Feature

HX125/25 Type of corn mill features:
advanced structure, complete specifications, new and beautiful appearance, reasonable design.

Working Principle

HX12/5/25 Type of corn mill is designed for perfectly grinding in the wheat or corn flour mill. The milling rolls are running on self-aligning  roller bearings housed on a carbon steel beam and located on shock absorbers to reduce vibrations on the machine to achieve quiet running.

The main base of the machine has casting structure which is designed for heavy duty. Other frames are welded and appropriately processed by high quality steel plates for eliminating mechanical stress. This special design guarantees absorption of milling vibrations and noise free operation. The main drive between motor and fast roller is by 5V high tension belt and the transmission between milling rolls is by means of sprocket belt which could absorb the vibration and noise furthest. - The milling rolls are engaged by means of pneumatic SMC (Japan) air cylinders unit installed on both sides of the machine. The automatic Siemens (Germany) feeding roll system with micro PLC ensures that the materials can be fed into the rolls evenly and continually.

Note: Micro PLC control box is located in main MCC cabinet room.

Technical Parameter

Type: MX125/25
Capacity(t/h): corn grits: 2.5-3, corn flour: 0.45-0.5
Speed of fast roller(r/min): 450-600
Fast roller& slow roller speed ratio: 1.25:1, 2.5:1
Power(kw): 30-5.5
Weight(kg): 4100
Dimension(mm): 2072*1490*1920

After-sale Service


1. Precise design Proposal: Including Detailed Quotation List, CAD Flow Chat, Technological Index, Installation Diagram,and provide installed production line video and photos for customers reference.
2. Delivery Goods: Provide standard shipping wooden package, full set of equipments photos before and after packing goods.also, full set of shipping documets sent by post.
3. Plant Installation: Engineers is available to install machine oversea.
4. Quality Guarantee Term: 12 Months.
5. After-sales service: Malfunctions which are caused by machine-self and quality will be responsible for our manufacturer. Other malfunctions which are caused by operation mistakes, man-made problems, etc will be responsible for clients-self.
