Maize Germ Extraction Line

Product properties
  • Summary:

    Type: 6FYTPCT

    Output: 100-2000ton



Brief Introduction

This maize germ extraction line includes: removing impurity and stone, hulling, germ remove, selecting germ, fine germ select, sifter, dust elimination, suspending clean sift, pulverize, vertical transfer, horizontal transfer, air transfer, dust removal by ventilation and packing, to make sure our clients to get higher corn germ yield rate and purity (corn germ yield rate 8-9%, starch content under 10% and 95% of whole corn germ rate, compare with the industry standard. This production line is suitable for food manufactories, starch sugar manufactories, and brewery manufactories, alcohol manufactories and feed manufactories.

Function and Feature

The specific equipments different with the traditional wet milling extracting germ line used by starch manufactory and alcohol manufactory, the core equipments dry milling extracting germ and selecting germ both using our patent devices to guarantee our clients can get the best quality germ;

The flexible technics have high adaptability to the raw grains, design corresponding process depend on variously regions and quality of raw grains;

The maize germ extraction line adopts the most advanced technology, with the logical power equip, make this product more effected and saving more energy, the core devices also achieved the Chinese National Patent. This line is suitable for the corn front- end processing of alcohol manufactory, starch manufactory, feeds manufactory, meanwhile provide better corn germ for the next process.

Working Principle

The line use dry milling technologies. Compare with wet milling and semidry milling, the products do not need to be bake out, which reduce the cost for desiccation, e.g.: area, equipment, fuel, human resources etc., consequently reduce a major invest for our clients;
Compare the germ which produced by other corn flour manufactory our produce have no chemical pollution, high corn germ yield rate, high purity degree and high quality is an eco- product with higher health requirement;
The line has simple structure, high adjustability for the field area and the workshop, no special requirements. Effectively cut down the fixed investment. Simple installations, fast construct progress, short construction period, allow our clients to meet the benefits in the shortest possible time;

Technical Parameter

TYPE

POWER

(KW)

POWER

COST

(KW/H)

OUTPUT

T/24H

SIZE REQUIREMENT

(L×W×H mm)

100t

124

22-24

100

26×7×7.5

steel frame construction

200t

262

20-22

200

40×7×11

steel frame construction

300t

394

20-22

300

48×7×12

steel frame construction

500t

595

18-20

500

60×7×12

steel frame construction

1000t

1310

18-20

1000

48×9×18

              (storied building construction

2000t

2618

18-20

2000

60×9×22

story building construction
