MTPS-25B Fine Maize Huller

Product properties
  • Summary:

    Inside of the fine maize huller installs the air draft dedusting system, which ensures the best sanitation condition.MTPS-25B fine maize huller connects with highly efficient air indraft system, which ensures reliability of maize bran discharging. It has strong cooling system so as to ensure high sanitation standard.

Brief Introduction

The fine maize huller is used in the peeling and germ removing section in corn processing industry, and the preliminary cleaning section of breweries and feed enterprises.

Function and Feature

Fine maize huller has the features of easy operation and maintenance. Its sieve plate and other accessories are quick-replaceable. It has durable emery roll and less wearing parts. This feature makes fine maize huller easily operated and maintained.
Fine maize huller also has uniform end products and reliable quality. There are different adjustment choices for you even in the peeling process, for example, you can adjust feeding speed and outlet pressure to increase the friction and pressure in the peeling chamber so as to produce high quality end products.
It has moderate peeling process and high processing efficiency. Stable corn flow and the efficient air indraft system inside of the machine makes the peeling process moderate so as to reduce corn loss in processing and ensures the profit maximization.

Working Principle

The material is sent by the screw propeller to the center part of the fine maize huller, the hulling chamber. Then it utilizes emery roll that rotates with high speed to cut and rub the corn bran continuously and destroys the bonding strength between the maize bran and the corn endosperm and the germ, which makes corn bran separated. Then the material is conveyed to the discharging port and the hulling process is finished.


Technical Parameter



Model

Emery Roll
Diameter

(mm)

Emery Roll Length

(mm)

Spindle Speed

r/min

Yield

t/h

Power

kw

Air Volume

m³/h

Size

(L*W*H)

(mm)

MTPS-18Y/A

Φ180

660

1300

11.5

22



1370×700×1900

MTPS-18Y/B

Φ180

660

1300

11.5

22

1500-1800

1410×1220×2030

MTPS-25Y/A

Φ240

660

1050

2.5-3.5

30



1515×660×2100

MTPS-25Y/B

Φ240

660

1050

2.5-3.5

30

1800-2100

1515×1220×2100

MTPS-30Y/A

Φ300

800

850

4-6

37-45



1690×710×2180

After-sale Service

1. Timely provide Party A with all the technical materials and drawings as the contract; compile and supplement operation manual according to the final commissioning results.
2. Party B offers on-site training service according to progress of the project, installing, trying operation and production of the whole line as it is required on the technical materials and drawings.
3. Party B gives training of installation, commissioning, use and maintenance to staff of Party A under their arrangement.
4. Instruct operators and maintenance staff.
5. Increase pre-sale, in-sale and after-sale service, implementing super pre-sale, full process and life long service through manufacturing, installation, commissioning and production.
6. During warranty period, Party B will provide an answer or staff within 4 hours once receiving feedbacks about quality of the products. Party B will arrive at the site as soon as possible, change and maintain the spare parts for free. The service will never stop until the clients are satisfied.
7. Beyond warranty period, Party B is on call to provide paid service for improvement of technology, maintenance of the machine or offer of the spare parts.
